Details
Size guide: 1st external height, 2nd external width, 3rd thickness.
- Description
- Tech Specs
- Shipping
Our Glass Fibre Angles are pultruded in a polyester matrix to BS EN 13706 specifications. The fibreglass layup is a combination of multi layered cross-ply glass fibre fabrics, giving an enhanced across the axis strength for all round excellent mechanical properties.
Glass Fibre offers numerous benefits including a lightweight construction and a high strength-to-weight ratio that ensures reliable performance even under heavy loads. Its versatility and ease of handling makes it a practical, cost effective choice for a wide range of structural applications while its resistance to corrosion makes it an ideal choice for use in demanding environments. Glass Fibre can be easily machined and cut to size, allowing for easy customization to meet the unique requirements of your project.
Offering high performance and durability combined with ease of handling and installation, Glass Fibre is an ideal solution for a wide range of applications. Please ask the Plastock team for more information on our products and how we can help you achieve your project goals.
Colour | White |
Density (g/cm³) | 1.5-2 |
Water absorption (%) | 0.5-2 |
Construction | Pultrusion |
Resin Matrix | Polyester |
Fibre Orientation | Crossdirectional |
CLTE (10⁻⁶K⁻¹) | 7.2 |
Full Section Modulus | < 6mm thick: E17 (GPa17) |
6mm & >: E23 (GPa23) | |
Tensile strength axial (MPa) | E17: 170 |
E23: 240 | |
Tensile strength transverse (MPa) | E17: 30 |
E23: 50 | |
Flexural strength axial (MPa) | E17: 170 |
E23: 240 | |
Flexural strength transverse (MPa) | E17: 70 |
E23: 100 | |
Tensile modulus axial (MPa) | E17: 1.7x10⁴ |
E23: 2.4x10⁴ | |
Tensile modulus transverse (MPa) | E17: 0.5x10⁴ |
E23: 0.7x10⁴ | |
Inter-laminar shear (MPa) | E17: 15 |
E23: 25 | |
Pin bearing strength (MPa) | E17: 50 |
E23: 70 | |
Thermal conductivity (W/(m*K) | 0.2-0.5 |
Heat distortion temp (°C) | 125-145 |
Minimum order value excluding VAT & delivery is £25
What is the cost of delivery?
Because of the huge variation in our orders we have developed a specialised shipping calculator for clients ordering online. Once you fill out your order details and progress through to the online checkout, our calculator will automatically work out the precise shipping cost for you to check before you proceed.
What delivery methods do you use?
We have a selection of couriers suited to the size, weight and type of product you order from us. It is likely we will deliver your goods with a courier service such as Tuffnells, TNT, DHL etc. You can track your order with the shipment number, if you would like us to send you the tracking number for your order please contact us or give us a call and we can track it for you.
If you would like to specify any special delivery instructions these can be entered at the point of ordering or please give us a call once you have placed your order and we will try to accommodate your requests.
Delivery options...
- Collection. Once your order is ready for collection, we shall call you to advise. Our collection point is open until 5pm - Monday - Friday.
- Standard Delivery. All of our orders come with standard delivery which is typically a 1-3 working day service. Standard delivery assumes reasonable access and is to ground floor, or use of a suitable lift for anything above ground level.
- In a hurry? We can look into premium delivery services at an extra cost. Give us a call on 01494 449 975 to find out more.
- Installation. If required please get in touch about our installation services and how we can best support you, all with a smile!
See our shipping page for more details.
