NYLON 12
NYLON 12
Polyamide 12 (PA12)
Polyamide 12 (PA12)
Nylon 12, also known as Polyamide 12 (PA 12), is a high-performance thermoplastic polymer derived from laurolactam. It is distinguished from other polyamides by its unique molecular structure, specifically its long hydrocarbon chain which results in the lowest water absorption rate of all commercial nylons.
Nylon 12 acts as a bridge between lower-performance engineering plastics and high-cost specialty polymers, offering an exceptional balance of mechanical toughness, chemical resistance, and dimensional stability.
Key Properties
Mechanical & Physical
- Superior Impact Resistance
Maintains high toughness even at sub-zero temperatures (down to -40°C). - Low Water Absorption
Minimal moisture uptake ensures parts remain dimensionally stable and retain mechanical properties in humid or wet environments. - Chemically Inert
Exceptional resistance to oils, greases, fuels, hydraulic fluids, and many solvents. - High Fatigue Resistance
Capable of enduring repetitive stress and bending without cracking or failure.
Chemical & Thermal
- Low Friction & Wear
Excellent sliding properties and abrasion resistance, making it ideal for moving parts. - Stress Crack Resistance
Highly resistant to chemicals that typically cause cracking in other plastics. - Process Versatility
Compatible with injection moulding, extrusion, and advanced 3D printing (SLS and Multi Jet Fusion). - Lightweight
One of the lowest densities among polyamides, contributing to fuel efficiency in transport applications.
COMMON APPLICATIONS
Technical Details
| TEST METHOD | VALUE | VALUE (IMPERIAL) | |
|---|---|---|---|
| PHYSICAL PROPERTIES | |||
| Density | ISO 1183 | 1.01 g/cm³ | 0.036 lb/in³ |
| Water Absorption (24h) | ISO 62 | 0.1% | 0.1% |
| Water Absorption (Saturation) | ISO 62 | 1.4% | 1.4% |
| MECHANICAL PROPERTIES | |||
| Tensile Strength at Yield | ISO 527 | 45 MPa | 6,500 psi |
| Tensile Modulus of Elasticity | ISO 527 | 1,400 MPa | 203 ksi |
| Elongation at Yield | ISO 527 | 5% | 5% |
| Elongation at Break | ISO 527 | 15% | 15% |
| Flexural Strength | ISO 178 | 50 MPa | 7,250 psi |
| Flexural Modulus | ISO 178 | 1,200 MPa | 174 ksi |
| Charpy Impact (Notched) | ISO 179 | 7 kJ/m² | 3.3 ft-lb/in² |
| Rockwell Hardness | ISO 2039-2 | R 105 | R 105 |
| THERMAL PROPERTIES | |||
| Melting Temperature | ISO 11357 | 178°C | 352°F |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 45°C | 113°F |
| Max. Service Temp (Long Term) | IEC 60216 | 80–100°C | 176–212°F |
| Min. Service Temp | -40°C | -40°F | |
| Thermal expansion (CLTE) | ISO 11359 | 120 x 10⁻⁶/K | 6.7 x 10⁻⁵ in/in/°F |
| Thermal Conductivity | DIN 52612 | 0.24 W/(m·K) | 1.66 BTU·in/(hr·ft²·°F) |
| Flammability Rating | UL 94 | HB | HB |
| ELECTRICAL PROPERTIES | |||
| Dielectric Strength | IEC 60243 | 30 kV/mm | |
| Volume Resistivity | IEC 60093 | 10¹³-10¹⁵ Ω·cm | |
| Surface Resistivity | IEC 60093 | 10¹³-10¹⁴ Ω | |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.0 | |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.02 |
Values are representative of typical unfilled, injection-moulded Nylon 12.
They are typical average values and should be used for material selection and design guidance only.
Technical Details
| TEST METHOD | VALUE | |
|---|---|---|
| PHYSICAL PROPERTIES | ||
| Density | ISO 1183 | 1.01 g/cm³ |
| Water Absorption (24h) | ISO 62 | 0.1% |
| Water Absorption (Saturation) | ISO 62 | 1.4% |
| MECHANICAL PROPERTIES | ||
| Tensile Strength at Yield | ISO 527 | 45 MPa |
| Tensile Modulus of Elasticity | ISO 527 | 1,400 MPa |
| Elongation at Yield | ISO 527 | 5% |
| Elongation at Break | ISO 527 | 15% |
| Flexural Strength | ISO 178 | 50 MPa |
| Flexural Modulus | ISO 178 | 1,200 MPa |
| Charpy Impact (Notched) | ISO 179 | 7 kJ/m² |
| Rockwell Hardness | ISO 2039-2 | R 105 |
| THERMAL PROPERTIES | ||
| Melting Temperature | 178°C | |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 45°C |
| Max. Service Temp (Long Term) | IEC 60216 | 80-100°C |
| Min. Service Temp | -40°C | |
| Thermal expansion (CLTE) | ISO 11359 | 8120 x 10⁻⁶/K |
| Thermal Conductivity | DIN 526127 | 0.24 W/(m·K) |
| Flammability Rating | UL 94 | HB |
| ELECTRICAL PROPERTIES | ||
| Dielectric Strength | IEC 60243 | 30 kV/mm |
| Volume Resistivity | IEC 60093 | 10¹³-10¹⁵ Ω·cm |
| Surface Resistivity | IEC 60093 | 10¹³-10¹⁴ Ω |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.0 |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.02 |
Values are representative of typical unfilled, injection-moulded Nylon 12. They are typical average values and should be used for material selection and design guidance only.
CHEMICAL RESISTANCE
| CATEGORY | REPRESENTATIVE SUBSTANCE | RATING | NOTES |
|---|---|---|---|
| Acids (Weak) | Acetic Acid (10%) | B | Slight swelling over time. |
| Acids (Strong) | Hydrochloric Acid | C | Rapid degradation and loss of properties. |
| Alcohols | Ethanol, Isopropanol | A/B | Generally resistant, slight absorption at high temps. |
| Alkalis (Bases) | Sodium Hydroxide | A | Excellent resistance to basic solutions. |
| Aromatic Hydrocarbons | Benzene, Toluene | A | Excellent resistance, superior to Nylon 6 or 66. |
| Chlorinated Solvents | Methylene Chloride | C | Strong solvent effect, causes significant swelling. |
| Fuels | Petrol, Diesel | A | Industry standard for fuel line applications. |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A | Good resistance at room temperature. |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B | Surface oxidation possible over long exposure. |
| Water / Steam | Hot water | A | Hydrolytically stable up to 80°C. |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
CHEMICAL RESISTANCE
| CATEGORY | EXAMPLE | RATING |
|---|---|---|
| Acids (Weak) | Acetic Acid (10%) | B |
| Acids (Strong) | Hydrochloric Acid | C |
| Alcohols | Ethanol, Isopropanol | A/B |
| Alkalis (Bases) | Sodium Hydroxide | A |
| Aromatic Hydrocarbons | Benzene, Toluene | A |
| Chlorinated Solvents | Methylene Chloride | C |
| Fuels | Petrol, Diesel | A |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B |
| Water / Steam | Hot Water | A |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
