PEEK
Polyether Ether Ketone
Polyether Ether Ketone
Polyether Ether Ketone, known as PEEK, is a high-performance semi-crystalline engineering thermoplastic. Often regarded as the gold standard of polymers, PEEK belongs to the polyaryletherketone (PAEK) family. It is sought after for its unique combination of high mechanical strength, wide temperature resistance, and exceptional chemical stability.
Unlike many plastics that buckle under pressure or melt at high temperatures, PEEK maintains its structural integrity in environments that would cause other materials to fail. Its ability to be precision-machined or injection-moulded makes it a preferred alternative to metal in weight-sensitive applications.
Key Properties
Mechanical & Physical
- Extreme Temperature Resistance
Operates continuously at temperatures up to 250°C and briefly at even higher peaks. - High Mechanical Strength
Offers excellent tensile strength and stiffness, providing a high strength-to-weight ratio. - Exceptional Chemical Resistance
Virtually unaffected by most common organic and inorganic chemicals (with a few rare exceptions). - Flame Retardant
Low smoke and toxic gas emissions during combustion, with a V-0 flammability rating
Chemical & Thermal
- Biocompatibility
Inherently pure and inert, making it ideal for medical implants and food-contact applications. - Low Moisture Absorption
Maintains dimensional stability and mechanical properties even in high-humidity or submerged environments. - Radiation Resistance
Maintains its properties even after exposure to high doses of gamma radiation. - Versatile
If you need a material that is tough, clean, and resistant to almost everything, PEEK is usually the answer.
COMMON APPLICATIONS
Technical Details
| TEST METHOD | VALUE | VALUE (IMPERIAL) | |
|---|---|---|---|
| PHYSICAL PROPERTIES | |||
| Density | ISO 1183 | 1.32 g/cm³ | 0.0477 lb/in³ |
| Water Absorption (24h) | ISO 62 | 0.05% | 0.05% |
| Water Absorption (Saturation) | ISO 62 | 0.40% | 0.40% |
| MECHANICAL PROPERTIES (at 23°C) | |||
| Tensile Strength at Yield | ISO 527 | 100 MPa | 14,500 psi |
| Tensile Modulus of Elasticity | ISO 527 | 3,800 MPa | 551 ksi |
| Elongation at Yield | ISO 527 | 5% | 5% |
| Elongation at Break | ISO 527 | 20% | 20% |
| Flexural Strength | ISO 178 | 160 MPa | 23,200 psi |
| Flexural Modulus | ISO 178 | 3,700 MPa | 536.5 ksi |
| Charpy Impact (Notched) | ISO 179 | 4.0 kJ/m² | 1.9 ft-lb/in² |
| Rockwell Hardness | ISO 2039-2 | M 100 | M 100 |
| THERMAL PROPERTIES | |||
| Melting Temperature | ISO 11357 | 343°C | 649°F |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 152°C | 306°F |
| Max. Service Temp (Long Term) | UL 746B | 250°C | 482°F |
| Min. Service Temp | -50°C | -58°F | |
| Thermal expansion (CLTE) | ISO 11359 | 50 x 10⁻⁶/K | 2.8 x 10⁻⁵ in/in/°F |
| Thermal Conductivity | ISO 22007 | 0.25 W/(m·K) | 1.73 BTU·in/(hr·ft²·°F) |
| Flammability Rating | UL 94 | V-0 | V-0 |
| ELECTRICAL PROPERTIES | |||
| Dielectric Strength | IEC 60243 | 20 kV/mm | |
| Volume Resistivity | IEC 60093 | 10¹⁶ Ω·cm | |
| Surface Resistivity | IEC 60093 | 10¹⁵ Ω | |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.2 | |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.003 |
These values are typical averages and should be used for material selection and design guidance only.
Technical Details
| TEST METHOD | VALUE | |
|---|---|---|
| PHYSICAL PROPERTIES | ||
| Density | ISO 1183 | 1.32 g/cm³ |
| Water Absorption (24h) | ISO 62 | 0.05% |
| Water Absorption (Saturation) | ISO 62 | 0.40% |
| MECHANICAL PROPERTIES | ||
| Tensile Strength at Yield | ISO 527 | 100 MPa |
| Tensile Modulus of Elasticity | ISO 527 | 3,800 MPa |
| Elongation at Yield | ISO 527 | 5% |
| Elongation at Break | ISO 527 | 20% |
| Flexural Strength | ISO 178 | 160 MPa |
| Flexural Modulus | ISO 178 | 3,700 MPa |
| Charpy Impact (Notched) | ISO 179 | 4.0 kJ/m² |
| Rockwell Hardness | ISO 2039-2 | M 100 |
| THERMAL PROPERTIES | ||
| Melting Temperature | 343°C | |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 152°C |
| Max. Service Temp (Long Term) | UL 746B | 250°C |
| Min. Service Temp | -50°C | |
| Thermal expansion (CLTE) | ISO 11359 | 50 x 10⁻⁶/K |
| Thermal Conductivity | ISO 22007 | 0.25 W/(m·K) |
| Flammability Rating | UL 94 | V-0 |
| ELECTRICAL PROPERTIES | ||
| Dielectric Strength | IEC 60243 | 20 kV/mm |
| Volume Resistivity | IEC 60093 | 10¹⁶ Ω·cm |
| Surface Resistivity | IEC 60093 | 10¹⁵ Ω |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.2 |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.003 |
These values are typical averages and should be used for material selection and design guidance only.
CHEMICAL RESISTANCE
| CATEGORY | REPRESENTATIVE SUBSTANCE | RATING | NOTES |
|---|---|---|---|
| Acids (Weak) | Acetic Acid, Citric Acid | A | Excellent resistance at high temperatures. |
| Acids (Strong) | Sulfuric Acid, Nitric Acid | B/C | Dissolves in concentrated Sulphuric Acid.. |
| Alcohols | Ethanol, Isopropanol | A | Fully resistant. |
| Alkalis (Bases) | Sodium Hydroxide | A | Unaffected by strong bases even at elevated temps. |
| Aromatic Hydrocarbons | Benzene, Toluene | A | Highly resistant. |
| Chlorinated Solvents | Methylene Chloride | A | Generally resistant. |
| Fuels | Petrol, Diesel, Jet Fuel | A | Ideal for aerospace and automotive fuel systems. |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A | Excellent resistance, rare for a thermoplastic. |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B | Good resistance; check concentration and temp. |
| Water / Steam | Superheated Steam | A | Exceptional resistance to hydrolysis at 200°C+. |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
CHEMICAL RESISTANCE
| CATEGORY | EXAMPLE | RATING |
|---|---|---|
| Acids (Weak) | Acetic Acid, Citric Acid | A |
| Acids (Strong) | Sulfuric or Hydrochloric Acid | B/C |
| Alcohols | Ethanol, Isopropanol | A |
| Alkalis (Bases) | Sodium Hydroxide | A |
| Aromatic Hydrocarbons | Benzene, Toluene | A |
| Chlorinated Solvents | Methylene Chloride | A |
| Fuels | Petrol, Diesel, Jet Fuel | A |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B |
| Water / Steam | Superheated Steam | A |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
