NYLON 6
NYLON 6
Polyamide 6 (PA6)
Polyamide 6 (PA6)
Nylon 6, also known as Polyamide 6 (PA6), is one of the most widely used engineering thermoplastics worldwide. It is produced through the ring-opening polymerisation of caprolactam, a single monomer containing six carbon atoms. The process involves heating caprolactam at high temperatures (approx. 250°C–260°C) with water and a catalyst to break the cyclic structure and form long linear polyamide chains.
The result is a material that strikes an impressive balance between strength, ductility (plasticity), and cost-effectiveness. It is particularly favoured for its "toughness", having a high impact resistance even at low temperatures, although it is famously thirsty, absorbing moisture from its environment which subtly changes its mechanical properties over time.
Key Properties
Mechanical & Physical
- Exceptional Toughness
High impact resistance even at low temperatures. - Hygroscopic Nature
Absorbs water, which acts as a plasticiser, increasing impact strength while slightly reducing tensile strength and stiffness. - Surface Finish
Naturally high gloss and easy to colour, making it a favourite for aesthetic consumer parts.
Chemical & Thermal
- Wear Resistance
Low coefficient of friction, providing great self-lubricating properties in dry-running applications - Chemical Resistance
Highly resistant to hydrocarbons (oils, fats, fuels). - High Elasticity
Excellent fatigue resistance and damping properties.
COMMON APPLICATIONS
Technical Details
| TEST METHOD | VALUE | VALUE (IMPERIAL) | |
|---|---|---|---|
| PHYSICAL PROPERTIES | |||
| Density | ISO 1183 | 1.13 g/cm³ | 0.041 lb/in³ |
| Water Absorption (24h) | ISO 62 | 1.3-1.8% | 1.3-1.8% |
| Water Absorption (Saturation) | ISO 62 | 8.5-10% | 8.5-10% |
| MECHANICAL PROPERTIES | |||
| Tensile Strength at Yield | ISO 527 | 80 MPa | 11,600 psi |
| Tensile Modulus of Elasticity | ISO 527 | 2,800 MPa | 406.1 ksi |
| Elongation at Yield | ISO 527 | 4% | 4% |
| Elongation at Break | ISO 527 | >50% | >50% |
| Flexural Strength | ISO 178 | 100 MPa | 14,500 psi |
| Flexural Modulus | ISO 178 | 2,600 MPa | 377 ksi |
| Charpy Impact (Notched) | ISO 179 | 6.0 kJ/m² | 2.85 ft-lb/in² |
| Rockwell Hardness | ISO 2039-2 | R 116 | R 116 |
| THERMAL PROPERTIES | |||
| Melting Temperature | ISO 11357 | 220°C | 428°F |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 65°C | 149°F |
| Max. Service Temp (Long Term) | UL 746B | 80-100°C | 176-212°F |
| Min. Service Temp | -40°C | -40°F | |
| Thermal expansion (CLTE) | ISO 11359 | 80 x 10⁻⁶/K | 4.4 x 10⁻⁵ in/in/°F |
| Thermal Conductivity | ISO 22007 | 0.25 W/(m·K) | 1.73 BTU·in/(hr·ft²·°F) |
| Flammability Rating | UL 94 | V-2 | V-2 |
| ELECTRICAL PROPERTIES | |||
| Dielectric Strength | IEC 60243 | 25 kV/mm | |
| Volume Resistivity | IEC 60093 | 10¹³ Ω·cm | |
| Surface Resistivity | IEC 60093 | 10¹³ Ω | |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.2 | |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.02 |
The values represent typical data for "Dry as Moulded" (DAM) unreinforced Nylon 6. Performance will shift significantly when conditioned to equilibrium moisture content.
They are typical average values and should be used for material selection and design guidance only.
Technical Details
| TEST METHOD | VALUE | |
|---|---|---|
| PHYSICAL PROPERTIES | ||
| Density | ISO 1183 | 1.13 g/cm³ |
| Water Absorption (24h) | ISO 62 | 1.3-1.8% |
| Water Absorption (Saturation) | ISO 62 | 8.5-10% |
| MECHANICAL PROPERTIES | ||
| Tensile Strength at Yield | ISO 527 | 80 MPa |
| Tensile Modulus of Elasticity | ISO 527 | 2,800 MPa |
| Elongation at Yield | ISO 527 | 4% |
| Elongation at Break | ISO 527 | >50% |
| Flexural Strength | ISO 178 | 100 MPa |
| Flexural Modulus | ISO 178 | 2,600 MPa |
| Charpy Impact (Notched) | ISO 179 | 6.0 kJ/m² |
| Rockwell Hardness | ISO 2039-2 | R 116 |
| THERMAL PROPERTIES | ||
| Melting Temperature | 220°C | |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 65°C |
| Max. Service Temp (Long Term) | UL 746B | 80-100°C |
| Min. Service Temp | -40°C | |
| Thermal expansion (CLTE) | ISO 11359 | 80 x 10⁻⁶/K |
| Thermal Conductivity | ISO 22007 | 0.25 W/(m·K) |
| Flammability Rating | UL 94 | V-2 |
| ELECTRICAL PROPERTIES | ||
| Dielectric Strength | IEC 60243 | 25 kV/mm |
| Volume Resistivity | IEC 60093 | 10¹³ Ω·cm |
| Surface Resistivity | IEC 60093 | 10¹³ Ω |
| Dielectric Constant (1 MHz) | IEC 60250 | 3.2 |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.02 |
The values represent typical data for "Dry as Moulded" (DAM) unreinforced Nylon 6. Performance will shift significantly when conditioned to equilibrium moisture content. They are typical average values and should be used for material selection and design guidance only.
CHEMICAL RESISTANCE
| CATEGORY | REPRESENTATIVE SUBSTANCE | RATING | NOTES |
|---|---|---|---|
| Acids (Weak) | Acetic Acid, Citric Acid | B | Generally okay for short-term contact. |
| Acids (Strong) | Sulfuric Acid, Hydrochloric Acid | C | Attacks the amide bond, causes rapid degradation. |
| Alcohols | Ethanol, Isopropanol | B | Slight swelling may occur over time. |
| Alkalis (Bases) | Sodium Hydroxide | A | Excellent resistance to basic solutions. |
| Aromatic Hydrocarbons | Benzene, Toluene | A | Very resistant to aromatic solvents. |
| Chlorinated Solvents | Methylene Chloride | C | Can cause significant swelling or dissolution. |
| Fuels | Petrol, Diesel | A | Primary reason for use in automotive fuel systems. |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A | High resistance to common ketones. |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B/C | Susceptible to oxidation at higher temperatures. |
| Water / Steam | Hot water, saturated steam | B | Hydrolysis can occur with prolonged steam exposure. |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
CHEMICAL RESISTANCE
| CATEGORY | EXAMPLE | RATING |
|---|---|---|
| Acids (Weak) | Acetic Acid, Citric Acid | B |
| Acids (Strong) | Sulfuric or Hydrochloric Acid | C |
| Alcohols | Ethanol, Isopropanol | B |
| Alkalis (Bases) | Sodium Hydroxide | A |
| Aromatic Hydrocarbons | Benzene, Toluene | A |
| Chlorinated Solvents | Methylene Chloride | C |
| Fuels | Petrol, Diesel | A |
| Ketones | Acetone, Methyl Ethyl Ketone (MEK) | A |
| Oxidizing Agents | Hydrogen Peroxide, Chlorine | B/C |
| Water / Steam | Hot water, saturated steam | B |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
