High Impact Polystyrene
High Impact Polystyrene
High Impact Polystyrene (HIPS) is a versatile, economical, lightweight and impact-resistant thermoplastic created by modifying general-purpose polystyrene with polybutadiene rubber.
HIPS strikes an ideal balance between stiffness and toughness. It is often used in vacuum forming, printing, and packaging due to its excellent impact resistance and low cost. It is easily fabricated by sawing, cutting, or drilling, and is widely used for signage, toys, and appliance components.
Key Properties
Mechanical & Physical
- Impact Resistance
Unlike brittle standard polystyrene, the added rubber content allows HIPS to absorb energy without fracturing. - Easy to Process
HIPS is one of the easiest materials to thermoform, vacuum form, and injection mould. - Surface Finish
Naturally matte, HIPS can be easily painted, glued, and printed upon. - Insulation
HIPS provides solid electrical insulation properties for low-voltage applications.
Chemical & Thermal
- Dimensional Stability
HIPS maintains its shape and size exceptionally well under varying conditions. - Low Moisture Absorption
Excellent resistance to water makes HIPS suitable for high-humidity environments. - FDA/EU Compliant Grades
Many variants are FDA and EU compliant for food contact. - Recyclability
HIPS is a Category 6 plastic, making it widely recyclable.
COMMON APPLICATIONS
Technical Details
| TEST METHOD | VALUE | VALUE (IMPERIAL) | |
|---|---|---|---|
| PHYSICAL PROPERTIES | |||
| Density | ISO 1183 | 1.04 g/cm³ | 0.0376 lb/in³ |
| Water Absorption (24h) | ISO 62 | 0.05% | 0.05% |
| Water Absorption (Saturation) | ISO 62 | 0.10% | 0.10% |
| MECHANICAL PROPERTIES | |||
| Tensile Strength at Yield | ISO 527 | 205 MPa | 3,625 psi |
| Tensile Modulus of Elasticity | ISO 527 | 2000 MPa | 290 ksi |
| Elongation at Yield | ISO 527 | 1.5% | 1.5% |
| Elongation at Break | ISO 527 | 40% | 40% |
| Flexural Strength | ISO 178 | 40 MPa | 5,800 psi |
| Flexural Modulus | ISO 178 | 2,100 MPa | 304.5 ksi |
| Charpy Impact (Notched) | ISO 179 | 10 kJ/m² | 4.76 ft-lb/in² |
| Rockwell Hardness | ISO 2039-2 | R70 | R70 |
| THERMAL PROPERTIES | |||
| Melting Temperature | DSC | 220°C | 428°F |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 75°C | 167°F |
| Max. Service Temp (Long Term) | 70°C | 158°F | |
| Min. Service Temp | -10°C | 14°F | |
| Thermal expansion (CLTE) | DIN 53752 | 90 x 10⁻⁶/K | 50 x 10⁻⁶ in/in/°F |
| Thermal Conductivity | DIN 52612 | 0.17 W/(m·K) | 1.18 BTU·in/(hr·ft²·°F) |
| Flammability Rating | UL 94 | HB | HB |
| ELECTRICAL PROPERTIES | |||
| Dielectric Strength | IEC 60243 | 15 kV/mm | |
| Volume Resistivity | IEC 60093 | 10¹⁵ Ω·cm | |
| Surface Resistivity | IEC 60093 | 10¹⁴ Ω | |
| Dielectric Constant (1 MHz) | IEC 60250 | 2.5 | |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.0004 |
These values are typical average values and should be used for material selection and design guidance only.
Technical Details
| TEST METHOD | VALUE | |
|---|---|---|
| PHYSICAL PROPERTIES | ||
| Density | ISO 1183 | 1.04 g/cm³ |
| Water Absorption (24h) | ISO 62 | 0.05% |
| Water Absorption (Saturation) | ISO 62 | 0.10% |
| MECHANICAL PROPERTIES | ||
| Tensile Strength at Yield | ISO 527 | 25 MPa |
| Tensile Modulus of Elasticity | ISO 527 | 2,000 MPa |
| Elongation at Yield | ISO 527 | 1.5% |
| Elongation at Break | ISO 527 | 40% |
| Flexural Strength | ISO 178 | 40 MPa |
| Flexural Modulus | ISO 178 | 2,100 MPa |
| Charpy Impact (Notched) | ISO 179 | 10 kJ/m² |
| Rockwell Hardness | ISO 2039-2 | R70 |
| THERMAL PROPERTIES | ||
| Melting Temperature | DSC | 220°C |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 75°C |
| Max. Service Temp (Long Term) | 70°C | |
| Min. Service Temp | -10°C | |
| Thermal expansion (CLTE) | DIN 53752 | 90 x 10⁻⁶/K |
| Thermal Conductivity | DIN 52612 | 0.17 W/(m·K) |
| Flammability Rating | UL 94 | HB |
| ELECTRICAL PROPERTIES | ||
| Dielectric Strength | IEC 60243 | 15 kV/mm |
| Volume Resistivity | IEC 60093 | 10¹⁵ Ω·cm |
| Surface Resistivity | IEC 60093 | 10¹⁴ Ω |
| Dielectric Constant (1 MHz) | IEC 60250 | 2.5 |
| Dissipation Factor (1 MHz) | IEC 60250 | 0.0004 |
These values are typical average values and should be used for material selection and design guidance only.
CHEMICAL RESISTANCE
| CATEGORY | REPRESENTATIVE SUBSTANCE | RATING | NOTES |
|---|---|---|---|
| Acids (Weak) | Acetic Acid | A | Generally resistant to diluted acids. |
| Acids (Strong) | Nitric Acid | C | Strong oxidising acids cause degradation. |
| Alcohols | Ethanol | B | Surface may cloud or crazing may occur over time. |
| Alkalis (Bases) | Sodium Hydroxide | A | Highly resistant to basic solutions. |
| Aromatic Hydrocarbons | Benzene | C | Rapidly dissolves or severely softens HIPS. |
| Chlorinated Solvents | Methylene Chloride | C | Severe swelling and dissolution. |
| Fuels | Petrol, Diesel | C | Not suitable for contact with petroleum fuels. |
| Ketones | Acetone | C | Immediate attack, used as a solvent for HIPS. |
| Oxidizing Agents | Hydrogen Peroxide | B | Variable resistance depending on concentration. |
| Water / Steam | Water / Steam | A | Excellent water resistance, steam causes warping. |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
CHEMICAL RESISTANCE
| CATEGORY | EXAMPLE | RATING |
|---|---|---|
| Acids (Weak) | Acetic Acid | A |
| Acids (Strong) | Nitric Acid | C |
| Alcohols | Ethanol | B |
| Alkalis (Bases) | Sodium Hydroxide | A |
| Aromatic Hydrocarbons | Benzene | C |
| Chlorinated Solvents | Methylene Chloride | C |
| Fuels | Petrol, Diesel | C |
| Ketones | Acetone | C |
| Oxidizing Agents | Hydrogen Peroxide | B |
| Water / Steam | Water / Steam | A |
RATING SCALE:
A (Excellent): Little to no effect.
B (Good/Fair): Minor swelling or slight changes in properties; acceptable for short-term exposure.
C (Poor): Severe degradation or stress cracking. Not recommended.
