PPC Pinseal Beige Sheet | Plastock

PPC Pinseal Beige Sheet

by Plastock
£62.30 - £186.91
£62.30
£62.30 - £186.91
£62.30
excl. VAT
SKU
Choose a Sheet Length (mm)
Choose a Sheet Width (mm)
Choose a Thickness (mm)

PPC Pinseal Beige Sheet is a product with characteristics including high strength, high heat resistance and high chemical resistance.

PPC Pinseal Beige Sheet is a product with characteristics including high strength, high heat resistance and high chemical resistance. The long term service temperature range of PPC Sheet is from -30°C to 100°C and has a short term maximum service temperature of 150°C.

Typical fields of application for PPC Sheet include chemical engineering, tank building and ventilation manufacturing. PPC Sheet is a material well suited to CNC routing, welding and fabrication.

If you have a requirement for machined or finished PPC components please ask the Plastock team for more information.

Colour Beige
Density (g/cm³) 0.91
CLTE (10⁻⁶K⁻¹) 120
Comparative tracking index 600
Dielectric constant 2.5
Dielectric strength (kV/mm) 45
Elongation at break (%) >50
Heat deflection temperature (°C) 85
Melting temperature (°C) 165
Notched impact strength (kJ/m²) >40
Shore hardness (scale D) 69
Surface resistivity (Ω) >10__
Tensile modulus of elasticity (MPa) 1100
Thermal capacity (kJ/(kg*K) 1.7
Thermal conductivity (W/(m*K) 0.2
Volume resistivity (Ω*cm) >10__
Yield stress (MPa) 23
Flammability 3mm HB
Flammability 6mm HB
Service temp long term min (°C) -30
Service temp long term max (°C) 100
Service temp short term max (°C) 150
Material type Pinseal
